Cardboard Carton Box Die Knife Cutting Creasing Machine

Carton cutting machine is widely used to cut and crease cardboard and paper to make carton box
Model:
Work Size:
cutting tool:
Machine Power:
Voltage:
Availability:
  • CZ-D2
  • Changzhou
  • CZ-D2-006

Product Description

Cardboard Carton Box Die Knife Cutting Creasing Machine


1. Machine Description


 carton box cutting machine


1. Carton box cutting machine has multi cut tool, carton box die cutting machine is able to do cutting, press floding, and degree cutting work.

2. Cardboard digital cutter has a group of creasing wheels to make fold line on corrugated board, then the cardboard is easy to fold.

3. Carton cutting machine has different shapes and length of cutting blades for cutting different work pieces.

4. Carton box die cutting machine has a powerful vacuum table. high vacuum pressure can fix the cardboard firmly in cut process.

5. Cardboard digital cutter has accurate position through a laser registration device.

6. Digital die cutter is compatible with different software such as AI, Corel Draw, Auto CAD, etc.


Knife cutting head: The knife cutting head is suited for cutting softer, medium density cardboard. Like corrugated cardboard, carton box board, PP cardboard.

  corrugated board cutting machine


Creasing Wheel: Carton cutting machine has a group of crease wheels for folding carton, corrugated plastic and many other applications.


 cardboard cutting machine



V CUT: The tool can be set for cutting at 5 different angles  (0°, 15°, 22.5°, 30°, 45°).


corrugated cardboard cutting machine


Model

CZ-1625

Work Size

1600mm x 2500mm

Table Type

auto feeding table / flat table for optional

Warranty

3 years for machine

Cut Speed

≤ 1600mm/s

Cut Thickness

≤ 45mm

Safety Device

infrared sensors, responsive, safe and reliable.

Material Fixed Mode

vacuum table

Support software

Corel draw, AI, Auto CAD and etc

Supply Voltage

110V / 220V / 380V, 50HZ / 60HZ

Motor and Driver

Japanese Yaskawa / Taiwan Delta

Support Format

plt, ai, dxf, cdr, hpg, hpgl, etc


2. Machine Application


Cutting function: carton cutting machine can cut different work pieces such as corrugated paper, cardboard, offset paper, greyboard, rubber, honeycomb board, PP, PE, PVC, gasket, leather, carpet, textile, fabric and car mat.

Folding function: carton box cutting machine can fold corrugated paper, card paper and offset board into perfect folding line.

Function of dotted line: digital die cutter is used to fold them after half cutting corrugated paper and grey card paper, and to cut dotted line.

Draw function with marker pen: cardboard digital cutter can write text on corrugated board, foam, PVC, adhesive vinyl, leather, rubber, fabrics, high intensity reflective films, paper, cardboard, etc.

Punching function: carton box die cutting machine can punch holes on leather, cardboard, PVC, rubber, carpet and mat, and etc.


 cardboard box cutting machine


1. Carton cutting machine can cut and fold cardboard at high speed. Carton box cutting machine has two independent work heads and the work tools are interchangeable.

2. Table of this carton box die cutting machine is a vacuum table. This vacuum table endows the cutting machine has stronger suction capacity and can fix the cardboard firmly in work process.

3. Automatic tool set system makes tool replacement more convenient. After replace the knife tools, you just need to press the button and the depth of the knife tool will be set automatically. In this way, damage to the cutting table caused by manual operation error will be avoided.


3. Company


Shandong changzhou CNC Equipment Co.,Ltd. was established in 2008, locates in Jinan city of Shandong province. We are a well - known manufacturer of laser machine, CNC router, digital knife cutting machine in China, All machines gain CE, FDA, ISO 9001 certificate. We support you with high quality machine, excellent service and the competitive price. We have design team, quality inspector team, after sales service team to make sure the high quality machine and service.


cardboard cutting machine


1. We supply 2 years warranty for the carton box cutting machine. you can come to our factory to learn the carton box die cutting machine, it’s free of charge.

2. Operation manual and training videos are available for the digital die cutter.

3. Online face to face training is offered, our engineers can speak English.

4. 24 hours technical support is available for the cardboard digital cutter.

5. Quality inspect team will fully check and test the carton box cutting machine before shipment to ensure high quality and high stability.


4. FAQ


(1) How to choose a right carton box cutting machine?

Please share your material and application to us, we will recommend the right carton box cutting machine.

(2) Do you supply machine software?

Yes, carton cutting machine software is free and easy to operate.

(3) Is the carton box digital die cutter easy to use?

Yes, cardboard digital cutter is easy to operate. we supply operation manual and video.

You can operate the machine in two days with our assist.

(4) What's the payment term of the machine?

T / T (telegraphic transfer), L / C, Paypal, Western union. 30% payment as deposit, and the balance 70% pay before shipping.

(5) How should i learn to use the carton cutting machine?

We have user manuals, machine operation videos.

Our engineer also will teach you online by whatsapp, skype, email, video call and etc.
